 OCTG-Sucker Rod

Mar 08, 2022

 OCTG-Sucker Rod

The sucker rod is the slender rod of the pumping well, which is connected to the polished rod and the lower part of the sucker pump to transmit power.

The single length of the sucker rod is 7.62 or 8 meters and 9.14 meters, and the material is generally low-carbon alloy steel after quenching and tempering treatment. It is connected one by one with internal thread hoops in the oil pipe and extends to the piston at the underground oil layer. Reciprocating motion to pump oil. The length of the current oil well is generally about 2,000 meters. Take Shengli Oilfield as an example, the deepest is more than 3,000 meters.

Sucker Rod Classification:

Ordinary sucker rod: C, D, K, KD grade sucker rod

High-strength sucker rod: H grade, divided into HY, HL, KHL three types

Special Sucker Rod: Hollow Sucker Rod: Steel Rod

Continuous sucker rod: steel rod

Special sucker rod for screw pump: tapered thread sucker rod, plug-in sucker rod

Fiberglass sucker rod: fiber reinforced plastic sucker rod

Flexible sucker rod: carbon fiber composite sucker rod, wire rope sucker rod

Other types of sucker rods: electric heating sucker rods

Sucker rod code

From right to left are:

Sucker rod length, mm

Grade and type, C, D, K, KD, HL, HY, KHL

Nominal diameter of rod body, mm

Steel sucker rod code, CYG
